Technical Description

Material Type: Refer catalogue for material details

Width (W) : 150 mm

Angle (Φ) : 60 to 70

Order Type : Code-Size (W)-Φ-OC(*)
Example : PCU-CS2.1-150-70-N12

*For OC option Please refer to our catalogue

Item Code	W Mm		a mm	b mm	c mm	E mm	F mm	h mm	l mm	L1 mm	M mm	S mm	SL Kg	SL1 Kg	SLM Kg	WF Kg	WFM Kg	wt Kg
PCU-CS2.1-150-60	150	60	246.6	246.6	0	193.92	76.08	138.2	50	170	100	98.5	215(21.9)	7718(787.0)	9555(974.3)	123.6(12.6)	185.3(18.9)	41.5
PCU-CS2.1-150-65	150	65	241.35	241.35	0	206.49	63.51	138.6	40	170	104	93.2	484(49.3)	8012(816.9)	9555(974.3)	123.6(12.6)	185.3(18.9)	42.2
PCU-CS2.1-150-70	150	70	245.01	240.01	0	218.56	51.44	141.9	30	170	110	86.4	753(76.7)	8306(846.9)	9555(974.3)	123.6(12.6)	185.3(18.9)	43.5
